RadiSense® 9 kHz(20 MHz)–10 GHz laser powered E-field probe,

ISO – Miniature spherical six antenna elements laser powered field strength probe.

Specifications：

• Frequency range       :         RSS2010I＞9 KHz to 10 GHz (useable to 12 GHz)
                                              RSS2010S＞20 MHz to 10 GHz (useable to 12 GHz)

• Measuring range       :         0.1 V/m to 750 V/m

• Frequency response  :         +/- 1 dB

• Isotropy                      :        < +/- 0.25 dB up to 1 GHz

• Measuring speed       :         100 measurements/second
  For further technical specifications, please refer to datasheet.


Standard delivered including：

• 2.5m optic fibre cable fixed connected to the probe.

• PST2000A small probe stand.

• Carrying and protection case.

• Factory verification certificate.

• Hardcopy Quick Start Guide.

• USB stick containing PDF format product manual, datasheet and ISO17025 accredited calibration certificate (in case ordered separately).

Optimized Applications：CE Marking Anechoic Chamber.
